Engineered for Precision & Performance
Our Grade 1 Titanium Foil (Commercially Pure Grade 1) is the gold standard for applications requiring maximum formability and corrosion resistance. Known for its superior ductility, it can be easily stamped, bent, or deep-drawn into intricate shapes without cracking.
Key Technical Advantages
Superior Corrosion Resistance: Naturally forms a stable oxide layer, making it immune to salt water, chlorides, and organic acids.
Lightweight Strength: Offers the highest strength-to-weight ratio of any metal, allowing for significant weight savings in aerospace and RC projects.
Biocompatible & Non-Toxic: Safe for medical research, jewelry, and food-contact applications.
PropertyHigh Thermal Stability: Maintains integrity in extreme temperatures where aluminum or plastics would fail.
Typical Applications
Audio Engineering: High-end tweeter domes and headphone diaphragms for crystal-clear high frequencies.
Green Energy: Ideal for bipolar plates in Hydrogen Fuel Cells and water electrolysis.
Industrial: Chemical-resistant gaskets, shims, and precision liners.
Ultralight Gear: Custom heat shields for camping stoves or ultralight backpacking DIY.
Specifications Table
Property | Value |
Material | Grade 1 Commercially Pure Titanium (CP1) |
Purity | ≧99.9% Ti
|
Standard
| ASTM B265/ASME SB265 |
Thickness Range | 0.01mm - 0.1mm |
Surface Finish | Annealing |
Elongation
| ≧24%(Excellent formability) |
Purchase Guarantee and FAQ (Trust Builders)
Q1: Can I cut this foil with regular scissors?
A: Yes! For thicknesses below 0.05mm, standard craft scissors or a utility knife will provide a clean cut. For thicker foils, we recommend precision shears.
Q2: Do you provide certification?
A: Absolutely. Every order can be shipped with a Mill Test Report (MTR) confirming the chemical composition and mechanical properties of the batch.
Q3: Is it shipped in rolls or sheets?
A: To prevent kinking or creasing, we ship our foil securely wound on a reinforced core or flat-packed between rigid protective layers, depending on the dimensions.
