1. Materials：GR1/GR2/GR3/GR4/GR5/GR7/GR9/GR11/GR12/GR23 etc 2. Dimension: TK（20-200）x W(50-500) x L(10-1500）mm 3. Standard: ASTM B381,ASME SB381 4. Surface: Machined/Pickling 6. Condition: Annealing 7. MOQ: 100KG 8. Delivery time: 15-30 days ready for shipment. 9. Customizable: Metal composition/Dimensions 10. Payment Terms：30% advance payment，balance payment before delivery.
Product specifications
Boze Metal Products Co., Ltd. offers a wide range of titanium forging across many metal types, grades, and alloys. Our Titanium forging stock is available in many finishes and a large diameter range. All products are 100% inspected with guaranteed quality and quick turnarounds.
Boze Metal Products Co., Ltd. is proud to support the Aerospace, Industrial, Oil & Gas, Medical markets and much more. As a Titanium forging supplier, we are dedicated to fulfilling all customer requirements.
We can also melt special alloy ingot according to customers' requirement.
Product
Titanium and titanium alloy forged blocks
Processing method
Forging (large size)-Cold forming-Aging treatment-Annealing-Drilling (small size), wire-cutting and maching
Material
Gr.1, Gr.2, Gr.5, Gr.7, Gr.9, Gr.12, etc.
Standard
ASTM B381,ASME SB381
Advantages
High Strength, Anti-Corrosion, High-Temperature Resistance, Low Temperature Resistance, Eco-Friendly Metal,Good Thermal Conductivity
Typical Applications
Titanium forging products are used in aeronautic, medical, semi-conductor, chemical engineering & Petrochemical technology, electrolysis, electroplating
What is titanium forgings?
Titanium forging is a high-performance manufacturing process that heats and shapes titanium under extreme pressure to refine its grain structure, creating components that are stronger, tougher, and more durable than cast or machined parts, ideal for aerospace, medical, and defense due to superior strength-to-weight, corrosion resistance, and high-temperature tolerance. The process involves heating titanium to specific temperatures (around 1200-1400°C), pre-forming, shaping via presses or hammers, controlled cooling, and often finishing with machining and heat treatment for precise properties.
Key Benefits
Enhanced Mechanical Properties: Refines grain structure for superior strength, fatigue resistance, and toughness.
Corrosion & Heat Resistance: High resistance to corrosion and ability to withstand high temperatures.
The Forging Process
Material Selection: Choosing the right titanium alloy for the application.
Heating: Heating the titanium to specific forging temperatures (e.g., 1200°C - 1400°C) to make it malleable, often involving alpha/beta phases.
Pre-forming: Shaping the heated metal into a rough form.
Forging: Applying immense compressive force using presses, hammers, or specialized dies (open die, closed die, multi-directional) to achieve the final geometry.
Cooling: Gradual cooling to prevent internal stresses.
Heat Treatment: Further treatments (like annealing) to optimize mechanical properties.
Machining & Inspection: Precision machining to final dimensions and quality control checks.
